● Capable of switch electric circuit with load
● Adaptable to padlock device
● Contact position indication
● Capable of quickly releasing stored energy operation
● Highlighted of high making and breaking capacity
● High short-circuit current withstand capacity
● Used as main switch for household and similar installation

● Standard: IEC60947
● Pole No.: 1P, 2P, 3P, 4P
● Rated current(A): 63,80,100,125
● Rated voltage: 240/415V AC
● Rated frequency: 50/60Hz
● Rated short-circut making capacity: 3kA
● Rated withstand current: 2kA/1s
● Electro-mechanical endurance: 10000 cycles
● Connection capacity: Rigid conductor 25mm²
● Connection terminal:
   Screw terminal
   Pillar terminal with clamp
● Installation:
   On symmetrical DIN rail 35mm
