● Elegant appearance; cover and handle in arc shape make comfortable operation.
● Contact position indicating window
● Transparent cover designed to carry label.
● RCBO handle can be locked either at “ON” position or at “OFF” position to prevent
   unwanted operation of the product.
● Provides protection against earth fault/leakage current, short-circuit and overload
● High short-circuit capacity
● Provides complementary protection against direct contact by human body.
● Effectively protects electric equipment against insulating failure
● Contact position indication

●Standard:IEC61009
●Residual current characteristics: AC
●Pole No.: 1P+N
●Tripping curve: B,C,D
●Rated short-circuit capacity:10kA
●Rated current (A):6,10,16,20,25,32,40,50
●Rated voltage: 240V AC
●Rated frequency: 50/60Hz
●Rated residual operating current(mA):30,100,300
●Tripping duration: instantaneous≤0.1s
●Electro-mechanical endurance：4000 cycles
●Connection terminal: pillar terminal with clamp
●Connection capacity:
  Flexible conductor 10mm²
  Rigid conductor 16mm²
●Installation:
  On symmetrical DIN rail 35mm
